| Codice Art. | Mis. Pollici | Mis. mm | Q.tà per Scatola | Peso kg | Carico Lav. ton. | Carico Rott. ton. | A ± 1,2 mm | C ± 1,2 mm | D ± 0,5 mm | L ± 2 mm | E ± 2 mm | B ± 1 mm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| RL07-1102/6 | 1/4 | 6 | 10 | 0.05 | 0.50 | 3.00 | 11.9 | 19.8 | 6.4 | 46.8 | 28.7 | 7.9 |
| RL07-1103/8 | 5/16 | 8 | 10 | 0.09 | 0.75 | 4.50 | 13.5 | 21.3 | 7.9 | 53.0 | 31.0 | 9.7 |
| RL07-1104/10 | 3/8 | 10 | 10 | 0.14 | 1.00 | 6.00 | 16.8 | 26.2 | 9.7 | 63.2 | 36.6 | 11.2 |
| RL07-1105/11 | 7/16 | 11 | 10 | 0.17 | 1.50 | 9.00 | 19.1 | 29.5 | 11.2 | 78.0 | 42.9 | 12.7 |
| RL07-1106/12 | 1/2 | 12 | 10 | 0.33 | 2.00 | 12.00 | 20.6 | 33.3 | 12.7 | 83.3 | 47.8 | 16.0 |
| RL07-1107/16 | 5/8 | 16 | 10 | 0.62 | 3.25 | 19.50 | 26.9 | 42.9 | 16.0 | 106.5 | 60.5 | 19.1 |
| RL07-1108/20 | 3/4 | 20 | 10 | 1.07 | 4.75 | 28.50 | 31.8 | 50.8 | 19.1 | 126.5 | 71.4 | 22.4 |
| RL07-1109/22 | 7/8 | 22 | 10 | 1.64 | 6.50 | 39.00 | 36.6 | 57.9 | 22.4 | 148.0 | 84.1 | 25.4 |
| RL07-1110/25 | 1 | 25 | 5 | 2.28 | 8.50 | 51.00 | 42.9 | 68.3 | 25.4 | 167.0 | 95.3 | 28.7 |
| RL07-1111/28 | 1+1/8 | 28 | 5 | 3.36 | 9.50 | 57.00 | 46.0 | 73.9 | 29.5 | 190.0 | 107.9 | 31.8 |
| RL07-1112/32 | 1+1/4 | 32 | 4 | 4.31 | 12.00 | 72.00 | 51.6 | 82.6 | 32.8 | 209.6 | 119.1 | 35.1 |
| RL07-1113/35 | 1+3/8 | 35 | 3 | 6.14 | 13.50 | 81.00 | 57.2 | 92.2 | 36.1 | 232.7 | 133.3 | 38.1 |
| RL07-1114/38 | 1+1/2 | 38 | 3 | 7.81 | 17.00 | 102.00 | 60.5 | 98.6 | 39.1 | 254.0 | 146.0 | 41.4 |
