| Cod. Art. / Art. Code | W (mm) | P (mm) | H min. (mm) | H max. (mm) | Peso kg/mt (Weight kg/mt) | Carico lav. ton (WLL ton) | Carico rott. kN (BF kN) | Fusto (Drum) 200 lt (mt) | Fusto (Drum) 100 lt (mt) | Fusto (Drum) 50 lt (mt) | Fusto (Drum) 30 lt (mt) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| C08060DV/C | 6 | 18 | 7,8 | 22,2 | 0,83 | 1,1 | 45,2 | 600 | – | – | 100 |
| C08070DV/C | 7 | 21 | 9,1 | 25,9 | 1,17 | 1,5 | 61,6 | 500 | – | 100 | – |
| C08080DV/C | 8 | 24 | 10,4 | 29,6 | 1,51 | 2,0 | 80,4 | 400 | – | 100 | – |
| C08100DV/C | 10 | 30 | 13,0 | 37,0 | 2,25 | 3,2 | 126,0 | 200 | 100 | – | – |
| C08130DV/C | 13 | 39 | 16,9 | 48,1 | 3,90 | 5,3 | 212,0 | 150 | 50 | – | – |
| C08160DV/C | 16 | 48 | 20,8 | 59,2 | 5,79 | 8,0 | 322,0 | 100 | 50 | – | – |
| C08190DV/C | 19 | 57 | 24,7 | 70,3 | 8,39 | 11,2 | 454,0 | 75 | 25 | – | – |
| C08200DV/C | 20 | 60 | 26,0 | 74,0 | 9,00 | 12,5 | 503,0 | 50 | – | – | – |
| C08220DV/C | 22 | 66 | 28,6 | 81,4 | 10,9 | 15,0 | 608,0 | 50 | – | – | – |
| C08230DV/C | 23 | 69 | 30,2 | 81,0 | 12,8 | 16,0 | 665,0 | 50 | – | – | – |
| C08260DV/C | 26 | 78 | 33,8 | 96,2 | 15,2 | 21,2 | 849,0 | 30 | – | – | – |
| C08280DV/C | 28 | 84 | 36,4 | 104,0 | 17,6 | 25,0 | 985,0 | 30 | – | – | – |
| C08320DV/C | 32 | 96 | 41,6 | 118,0 | 23,0 | 31,5 | 1290,0 | 20 | – | – | – |
